| 产品特性：耐热性 | 是否进口：是 | 原产国/地区：韩国 |
| 加工定制：否 | 适用范围：垫片，电缆，线圈，电子元件等 | 品牌：DuckSung |
| 类型：高温玻璃布胶带 | 基材：玻璃布 | 厚度：0.21mm |
| 宽度：50mm | 长期耐温性：180℃ | 型号：221H |
宽度可按您的要求定做，最快当天可出货。千元以上免收上机损耗5mm=￥17.5，按您要求裁切的不方便退货哟。
￥5千以上请电话沟通。
快递首重￥15，续重省内￥1/KG，跨省￥6/KG左右，以快递实收为准。
深圳市君达电子有限公司
0755-86173511，86173512
13923720372
13691895131
song@kingdays.com
***，韩国一级代理
221H
SiliconeGlass Cloth Tape
PRODUCT DISCRIPTION
221H is a white glass cloth tape, single coated with a silicone adhesive.
TECHNICAL DATA
Classification | Unit | Typical values | Tolerance | Remarks |
Backing thickness | mm | 0.14 | 0.14~0.15 | ASTM D3652 |
Adhesive thickness | mm | 0.07 | 0.065~0.07 | ASTM D3652 |
Total tape thickness | mm | 0.21 | 0.205~0.215 | ASTM D3652 |
Liner description | - | - | - | - |
Color | - | White | - |
Adhesive to steel | gf/25mm | 1300 | 850~1300 | ASTM D3330 |
Tensile strength | kg/10mm | 19 | 18 over | ASTM D3759 |
Elongation | % | 5 | 4~6 | ASTM D3759 |
TYPICAL APPLICATIONS
Protect specific areas of an electronic parts. Insulating the parts of aircraft, electronic, trains and special electronic components. Holding, sealing, splicing. High-temp application.
FEATURES AND BENEFITS
Excellent heat, cold, solvent and voltage resistance. Flame retardant.
